ATNJ Dual Band 1800MHz 2600MHz 5G LTE Signal Booster with Intelligent AGC

Name: ATNJ Dual Band 1800MHz 2600MHz 5G LTE Signal Booster with Intelligent AGC
Brand: ATNJ
Price: 230 USD

Quality ATNJ Dual Band 1800MHz 2600MHz 5G LTE Signal Booster with Intelligent AGC for sale

Model Number : AS-LTE+5G

Place of Origin : China

Brand Name : ATNJ

Price : $230/sets 1-99 sets

Type : 5g signal booster

Network : GPRS, 4g, GSM, 3G, 5G, LTE

Frequency Range : Band3 1800MHz+Band N41 2600MHz

Gain : 70dB,UpLink Gp≥68 DL Gp≥70, Uplink Gp≥68dB Downlink Gp≥68dB,

Output Power : 20dBm

AGC Intelligent Function : Done,31dB @ 1dB/ Step

RF Connect Type : SMA/Female Connector

Origin : Shenzhen,CN

Trademark : ATNJ

Contact Now

ATNJ Dual Band 1800MHz 2600MHz 5G LTE Signal Booster with Intelligent AGC

Product Description

Specification

LTE 1800 Performance Characteristics
	Uplink	Downlink
Frequency range	1710MHz-1785 MHz	1805 MHz-1880 MHz
Bandwidth	75 MHz	75MHz
Output power	17±2dBm	17±2dBm
Device gain	60±3dB	65±3dB
ALC/AGC Range	≥30dB	≥30dB
Noise	≤9dB	≤9dB
Ripple in band	≤8dB	≤8dB
VSWR	≤2.0dBm	≤2.0dBm
ACLR(dBc)	≤-36	≤-36
Time delay	≤3.0μs	≤3.0μs
Spurious emission	9kHz～150kHz	≤-36dBm @1kHz
		150kHz～30MHz	≤-36dBm @10kHz
		30MHz～1GHz	≤-36dBm @100kHz
		1GHz～12.75GHz	≤-30dBm @1MHz
EVM	≤3.5%	≤3.5%
TDD-NR 2600 Performance Characteristics
	Uplink	Downlink
Frequency range	2496-2690MHz
Bandwidth	195 MHz
Output power	17±2dBm	17±2dBm
Device gain	60±3dB	60±3dB
ALC/AGC Range	≥30dB	≥30dB
Noise	≤9dB	≤9dB
Ripple in band	≤5dB	≤5dB
VSWR	≤2.0dBm	≤2.0dBm
ACLR(dBc)	≤-36	≤-36
Time delay	≤3.0μs	≤3.0μs
Spurious emission	9kHz～150kHz	≤-36dBm @1kHz
		150kHz～30MHz	≤-36dBm @10kHz
		30MHz～1GHz	≤-36dBm @100kHz
		1GHz～12.75GHz	≤-30dBm @1MHz
256QAM EVM	≤3.5%	≤3.5%
Performance Characteristics
Working voltage	DC 5.0V
Working current	≤3.0A
Power adapter input voltage	AC 100～240V,50/60Hz
Power comsumption	≤15W
Enviroment temperature	-25℃～+55℃
relative humidity	≤85%
Device connection type	SMA-K
Power port	KLD-35-13
Device size	205×170×38mm
Weight	≤1Kg

Selling Point

. Support the network extension coverage of NSA and SA networking mode at the same time
. MIMO dual channel input and output to improve system capacity and energy efficiency
. Isolation detection of donor and retransmission antenna
. Large AGC range
. High speed digital ALC
. Output power indication
. Automatic Dormancy
. When the equipment is self-excited, it will turn off automatically
. Unique equipment uplink squelch function, which does not interfere with the base station
. Automatic balance of uplink and downlink gain
. Small size, light weight, beautiful appearance, high gain and low power consumption
. Different output power levels to meet different coverage requirements
. Low noise amplification of equipment to improve voice quality and reduce dropped calls
. Convenient installation and opening

Company Profile

Shenzhen ATNJ Communication Technology Company was founded in Nanshan District, Shenzhen in 2010 with over 900sqm factory. ATNJ focuses on the production and development of micro power signal booster, wireless signal repeater, Indoor Signal Distribution System and antenna series. With professional engineers, workers and with senior management personnel, the group maintains high-speed development. Meanwhile, the Up-to-date facilities and technology end sure the business long-term development. With the rapid development of the company, ATNJ moved to Guangming District, Shenzhen in 2016 with a bigger factory over 2450sqm and over 50 workers. Nowadays, ATNJ not only produces and develops high-quality home use signal booster and high power wireless repeater, but also expands its business scope to cooperate with signal operators, provide signal coverage solution for large area like residential area, office building, supermarket, underground garage and rural areas. In 2021, 5G signal booster was developed and put into Chinese market successfully. In addition, ATNJ starts to upgrade the signal booster from analog module to digital module, with which the products (micro power signal booster, wireless signal repeater, Indoor Signal Distribution System) could be operated and controlled with WIFI connection, WAN port, USB port and SIM card. Whats more, more functions are equipped in our products, like band select, sub bands, OLED screen display, MGC. With the progress of science and technology of ATNJ, easier use and more functional signal boosters have being developed.

FAQ

1. who are we?
We are based in Guangdong, China, start from 2010,sell to Domestic Market(35.00%),Eastern Europe(15.00%),Mid East(15.00%),Western Europe(6.00%),Oceania(5.00%),Northern Europe(5.00%),Southern Europe(5.00%),South Asia(5.00%),Southeast Asia(2.00%),Eastern Asia(2.00%),Central America(2.00%),North America(00.00%),South America(00.00%),Africa(00.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Wireless Repeater,Signal Booster,Signal Repeater,Indoor Signal Distribution System,Antenna

4. why should you buy from us not from other suppliers?
With professional engineers, workers and with senior management personnel, the group maintained high-speed development. Meanwhile, the Up-to-date facilities and technology end sure the business long-term development.

5. what services can we provide?
Accepted Delivery Terms: FOB,EXW,FCA,DDP,Express Delivery；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
